Who else is in the vehicle

Specified axle, braking and running-gear brands are written into the build sheet and held on repeat orders, so buyers can verify what is fitted.

Where the components come from

China: 56%
Europe: 22%
Japan, Korea, US & other: 22%

Strategic partners

Steel and liability, controlled at source. Both decide what happens long before a unit is built and long after it is delivered.

Shougang GroupChina
Strategic supply of tank shell steel plateMill-level control of plate grade
Ping An InsuranceChina
RMB 20 million product liability cover per vehicleEvery unit is covered, not a sample

Industry & academic

We help write the standards our own tankers are judged against, and develop the safety design with people outside the company.

China Chemical Equipment AssociationChina
Council member; co-drafted the national safety standards for refuelling and oil tankers
Tanker specialists & universitiesInternational
Joint research on the dual-safety design, new materials and new processes

Chassis & tractors

Bodies and tanks are built onto the chassis our customers already run, so the fleet keeps one service and parts arrangement.

FAW JiefangChina
Class II chassis conversion
DongfengChina
Class II chassis conversion
Sinotruk / HOWOChina
Class II chassis conversion
SAIC HongyanChina
Class II chassis conversion
Foton AumanChina
Class II chassis conversion
North BenzChina
Class II chassis conversion
SteyrChina
Class II chassis conversion
Mitsubishi FusoJapan
Chassis for concrete mixers
HinoJapan
Chassis for concrete mixers
IsuzuJapan
Chassis for concrete mixers
HyundaiSouth Korea
Chassis for concrete mixers

Running gear & braking

The parts that decide whether a loaded tanker stops and stays upright. European running gear is standard fitment on export units.

BPWGermany
Axles for hazardous-goods tankers, 400,000 km maintenance-freeOver 70% share of the Class III hazmat tanker market
FUWAChina
Axles
JOSTGermany
Kingpins and landing legsStandard on export units
WABCOGermany
Brake valves, relay valves, spring brake actuatorsStandard on export units
VIE ScienceChina
CM-TEBS electronic braking system
Liangshan DelphiChina
EBS safety management, EBD with 4S/4M

Production equipment

Welding is where a tank is won or lost, so the welding plant itself is bought to the same standard as the parts that go on the vehicle.

HUAHENGChina
Stainless steel plasma welding control systems
ERTAMATICFrance
Aluminium TIG welding (ERTAMATIC 50)
KemppiFinland
Welding equipment
KYKYChina
Molecular and rotary vane high-vacuum systemsLNG tank manufacturing

Specialist components

Hydraulics and drivetrain components for mixers and tippers, specified by part number so a replacement can be sourced locally.

EatonUnited States
Mixer reduction gears, hydraulic pumps and motors
HyvaNetherlands
Tipper hydraulic lifting cylinders (FC214-5-07130)

Customers

Search the parts library

Browse the full parts-family library across chassis, running gear, tanker, refrigeration and special-cargo systems. Select a record to carry its reference into the request form.

systems: 18
parts families: 735

Search the parts library

735 results

Part ID	Part	Typical specification	Material / finish	Key purchasing fields	Reference brand / series
PT-01-001	Main beam	Welded I-beam / variable-section beam / box beam, per drawing	Q355B / Q550 / Q690 / T700 high-strength steel	Section dimensions, upper/middle/lower flange plate thickness, yield strength, straightness, weld class	Factory drawing item
PT-01-002	Upper flange plate	8–20 mm common, designed per load	Q355B / Q550 / Q690	Width, thickness, material heat lot, bevel, NDT requirement	Steel mill / factory drawing item
PT-01-003	Lower flange plate	10–25 mm common, designed per load	Q355B / Q550 / Q690	Width, thickness, material heat lot, pre-camber	Steel mill / factory drawing item
PT-01-004	Main beam web	5–14 mm common, integral / splice-welded	Q355B / Q550 / Q690	Height, thickness, openings, stiffener spacing	Factory drawing item
PT-01-005	Side rail	Channel steel / bent beam / extruded profile	Q235B / Q355B / 6061-T6 aluminum	Section, length, wall thickness, surface treatment	Factory drawing item
PT-01-006	Crossmember	C / U / hat-shaped / box section	Q235B / Q355B / high-strength steel	Section, spacing, quantity, connection method	Factory drawing item
PT-01-007	Suspension crossmember	Per axle spacing and suspension drawing	Q355B / Q550	Suspension model, hole pitch, welding location, fatigue requirement	Factory drawing item
PT-01-008	Gooseneck beam	Fixed type / detachable type / hydraulic type	Q355B / Q550 / Q690	Fifth wheel height, neck length, locking structure, concentrated load	Trail King / factory design
PT-01-009	Coupler plate	8–16 mm common, per kingpin system	Q355B / wear-resistant steel	Thickness, flatness, kingpin hole, lubrication surface	JOST / SAF-HOLLAND interface
PT-01-010	Kingpin reinforcement plate	Round / square reinforcement plate	Q355B / Q550	Size, thickness, welding and bolting scheme	Factory drawing item
PT-01-011	Front crossmember	Closed type / open type	Q355B / aluminum alloy	Section, crash and torsion requirements, wiring hole	Factory drawing item
PT-01-012	Rear crossmember	Integrated lamp bracket / separate type	Q235B / Q355B / aluminum alloy	Lamp openings, license plate position, anti-collision connection	Factory drawing item
PT-01-013	Chassis diagonal brace	Angle steel / channel steel / tube	Q235B / Q355B	Section, length, welding location	Factory drawing item
PT-01-014	Reinforcement gusset	Triangular / bent / cover plate	Q355B / Q550	Thickness, radius, weld toe transition, layout	Factory drawing item
PT-01-015	Torsion box	Integral box / segmented type	Q355B / Q550 / Q690	Torsional stiffness, plate thickness, bulkheads, weld NDT	Heavy-duty engineered part
PT-01-016	Subframe	Body mounting subframe	Q355B / Q550	Chassis hole positions, flexible / rigid connection, load transfer	Factory drawing item
PT-01-017	Toolbox bracket	Bolted type / welded type	Galvanized steel / stainless steel / aluminum	Box dimensions, load capacity, hole pitch, mounting side	General
PT-01-018	Spare-wheel carrier bracket	Swing arm / winch / basket type	Q235B galvanized / stainless steel	Tire size, quantity, lowering space, locking	General
PT-01-019	Blast-primer system	Sa 2.5; epoxy zinc-rich / zinc phosphate	Epoxy resin / zinc powder system	Dry film thickness, surface roughness, salt spray target, color	AkzoNobel / PPG / Jotun etc.
PT-01-020	Topcoat & marking	Polyurethane / acrylic; RAL color code	Two-component PU / acrylic	Color, gloss, total film thickness, UV / chemical resistance, marking template	Industrial coating system
PT-02-001	2-inch kingpin	ISO type; 50.8 mm	Forged alloy steel, quenched / surface hardened	Mounting type, D value, flange thickness, bolted / welded, certification	JOST / SAF-HOLLAND
PT-02-002	3.5-inch kingpin	Heavy-duty type; 88.9 mm	Forged alloy steel, quenched	Rated load, connecting plate thickness, installation dimensions, certification	JOST / SAF-HOLLAND
PT-02-003	Kingpin bolt kit	High-strength bolt type	10.9 / 12.9 grade alloy steel	Thread, length, preload torque, anti-loosening method	JOST / SAF-HOLLAND
PT-02-004	Landing gear set	Two-speed 28–32 t static load / about 24 t lifting common	High-strength steel, galvanized / painted	Static load, lifting load, stroke, installation height, crank handle position	JOST Modul / SAF MARK V / FUWA

This is a maximum parts-family library, not a vehicle BOM or live stock list. Final compatibility, material, certification and availability are confirmed against the vehicle record and approved technical documents before quotation.

Send us the specification you have to meet

If a tender names a brake, axle or suspension brand, or your fleet already standardises on one, tell us which and we will confirm what we can fit before you commit to an order.
